Internal Hard Drives

Internal Hard Drive

S300 Pro

Capture Every Detail

Toshiba’s 3.5-inch S300 Pro Surveillance Hard Drive is designed and tested for 24/7 reliable surveillance, built for speed, capacity, and longer content retention. Capture and analyse every frame from up to 64 video cameras in high resolution with the S300 Pro. Space is important to continually capture a history of video evidence over a period of time. With up to 10 TB you get the capacity to record and play back the events in real-time in high resolution and with object identification and face recognition.

Use for:
• Surveillance Digital Video Recorders (sDVR)
• Surveillance Network Video Recorders (sNVR)
• Hybrid sDVR (analog and IP)
• RAID Storage Arrays for Surveillance

3.5″ SATA Hard Drive

7200 RPM

512 MB buffer

24/7 Operation

Supports up to 64 Video Cameras

High-Endurance Design

5-year Warranty

10 TB 8 TB 6 TB 4TB

BUILT TO PERFORM

With up to 10 TB of storage capacity and support for up to 64 video cameras, the S300 Pro ensures mission-critical surveillance continually records. Real-time drive performance allows higher-resolution video recording and streaming and longer content retention.

CAPTURE EVERY FRAME, ANALYSE EVERY DETAIL

When analyzing security footage, you can’t risk any frame drops. That’s why your storage has to provide ultimate performance to detect rapid movements, record the smallest details, and perform face recognition. The S300 Pro has been designed to meet your specialist demands and is built for 24/7 reliability and high-performance to help you never miss a thing.

S300 Pro | Surveillance Hard Drives

TOSHIBA Surveillance HDDs deliver high reliability, comfortable operability, temperature durability and – of course – large capacity.

DESIGNED AND TESTED FOR COMPATIBILITY

The S300 Pro has been designed and tested to support up to 64 high resolution cameras, allowing flexible scalability for your security camera systems. Compatible with DVR, NVR, video servers and video management systems for around-the-clock security, the surveillance never sleeps – so that you can.

toshiba-internal-hard-drive-s300pro-surveillance

toshiba-internal-hard-drive-s300-performance

INDUSTRY-LEADING PERFORMANCE

A 512 MB buffer and high transfer rates meet the demands of surveillance data from higher-resolution camera streams. Improved real-time drive performance is achieved through Toshiba’s Dynamic Cache Technology optimizing read and write cycle cache allocation through an on-board cache algorithm and buffer management.

INTEGRATED RV SENSORS

Regular hard disk drives without RV sensors can affect the performance of a multi-bay system by generating ‘knock-on’ vibration. The S300 Pro ensures high reliability by minimising vibration effects through their advanced control and sensing technology. Multiple sensors detect the slightest shock and built-in RV sensors also compensate for rotational vibration – eliminating the possibility of ‘knock-on’ vibration in multi-bay surveillance systems.

toshiba-internal-hard-drive-s300-RV_Sensor

toshiba-internal-hard-drive-s300-endurance_reliability

HIGH ENDURANCE, HIGH RELIABILITY

The high-endurance, high-performance components of the S300 Pro withstand harsh environments for superior reliability. High-temperature environments trigger optimized seek speed to support lower power consumption while automatically reducing noise and vibration emissions. Up to 1.2 million hour MTTF (Mean time to failure) and 300 TB per year workload rating provide peace of mind when operating security camera systems.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system. A 5-years extended warranty is also included with the S300 Pro for the ultimate peace of mind.

toshiba-internal-hard-drive-s300pro-warranty

Product Specifications

toshiba-internal-hard-drives-dimension-x300

Product Range

S300 Pro Hard Drives

Part number Capacity Buffer size Recording Type

HDWTA1AUZSVA 10 TB 512 MB CMR

HDWTA80UZSVA 8 TB 512 MB CMR

HDWTA60UZSVA 6 TB 512 MB CMR

HDWTA40UZSVA 4 TB 512 MB CMR
MORE

HDWT31AUZSVA 10 TB 256 MB CMR

HDWT380UZSVA 8 TB 256 MB CMR

HDWT360UZSVA 6 TB 256 MB CMR

HDWT140UZSVA 4 TB 128 MB CMR

Download Datasheet

Internal Hard Drive

N300

Built for 24/7 reliability

Toshiba 3.5 吋 N300 NAS 硬碟，提供 NAS 前所未有的可靠性及其他高效能儲存系統。可靠性、耐用度、效能及擴充能力均經最佳化，全年無休有效支援個人、家庭辦公、小型企業的高容量儲存需求。N300 容量最高可達 16 TB。

用途：

• 網路附加儲存裝置 (NAS)

• 桌上型 RAID 及伺服器

• 多媒體伺服器儲存裝置

• 私有雲端儲存裝置

• 小型企業伺服器及儲存裝置

3.5 吋 SATA 硬碟
7200 RPM
128/256/512 MB 緩衝區
支援 1 至 8 插槽 NAS
高可靠性及強化即時效能
Toshiba 動態快取技術
Toshiba 穩定磁盤技術
最適用於：個人、家庭辦公、小型企業使用
溫度控制
3 年保固
運轉全年無休
錯誤復原控制

16 TB 14 TB 12 TB 10 TB 8 TB 6 TB 4 TB

專為 NAS 所設計

自從與 NAS 製造商接觸之後，Toshiba 認為必須有高可靠性硬碟來支援現代的資料儲存和擷取需求，諸如串流、備份和封存等。這款磁碟機支援多磁碟陣列 (RAID) 系統，最多可達 8 個硬碟，允許多個用戶端全年無休存取大量資料，穩定可靠。

整合式 RV 感應器

一般沒有內建 RV 感應器的硬碟會產生「敲擊」振動而影響多插槽 NAS 系統的效能。N300 磁碟機利用其先進的控制和感應技術將這種振動降到最低，因此保障了高可靠性。多重感應器可偵測輕微震動，並且內建 RV 感應器同時補償旋轉振動 ─ 有效消除多插槽 NAS 構型系統中可能的「敲擊」振動。

N300 | NAS 硬碟

高可靠性的 TOSHIBA NAS 硬碟提供來自不同應用程式和位置的便捷資料共用，最大容量高達 16 TB。

可靠的全程待命運作

小型企業或創意環境中的 NAS 系統通常會有多位使用者從不同位置同時存取。因此，今日的 NAS 磁碟機必須提供高資料傳輸率，並且全年無休同時上傳及下載。N300 磁碟機提供絕佳可靠性與擴充能力，每年最高可達 180 TB 工作負載規格，是一般桌上型電腦硬碟的三倍。

toshiba-internal-hard-drive-n300-always-on

toshiba internal hard drive n300 durability heat prevention

高耐用性和預防過熱

使用高耐用度組件是 N300 系列比其他傳統硬碟機提供更高耐用性的原因之一。同時，自動調整搜尋速度可降低高溫運作期間的熱能，進一步提高了在高需求情況下的耐久性

可因應多硬碟環境的高速度

多虧有了 512、256 或 128 MB 資料緩衝區，才得以在多位使用者大量存取資料時實現高效能和高速讀取的能力。因此，這款硬碟適合想要在多 RAID NAS 環境中處理大量資料的小型企業和創意專業人士

toshiba-internal-hard-drive-n300-warranty

全球創新

50 多年來，Toshiba 在全世界一直以領先創新而著名，其硬碟系列產品的強力支持亦功不可沒。Toshiba 硬碟專為高容量和優異效能而設計，您可以確定 Toshiba 在硬碟方面的豐富經驗，能讓您的儲存系統順暢運作。N300 並提供三年保固，讓您絕對安心使用

Product Specifications

toshiba-internal-hard-drives-dimension-n300

Basic Specifications
Form factor	3.5-inch
Interface	SATA 6.0 Gbit/s
Drive bays supported	1 to 8
Rotational Vibration (RV) Sensors	Yes
Advanced Format (AF)	Yes
RoHS compatible	Yes
Halogen Free	Yes
Shock Sensor	Yes

Performance
Rotational speed	7200 rpm
Buffer size	512 MB (16 TB), 256 MB (6- 14 TB), 128 MB (4 -8 TB)
Data transfer speed	274MB/s (16 TB), 260MB/s (14 TB), 253MB/s (12 TB), 248 MB/s (10 TB), 241 MB/s (6 TB, 8 TB), 204 MB/s (4 TB)
Average latency	4.17 ms
Native Command Queing (NCQ)	supported

Reliability
Workloads	180 TB/year
MTTF	1,000,000 hours
Unrecoverable error rate	1 per 10E14 bits read
24/7 operation	Yes


Power Management
Supply voltage	5VDC (±5%) / 12VDC (±10%)
Consumption (operating)	6.91 W typ. (16 TB), 6.77 W typ. (14TB), 6.49 W typ. (12 TB), 9.48 W typ. (10 TB), 9.2 W typ. (8 TB), 10.1 W typ. (6 TB), 9.6 W typ. (4 TB)
Consumption - Active Idle	4.03 W typ. (16TB), 4.54 W typ.(14 TB), 4.28 W typ. (12 TB), 7.15 W typ (10 TB), 6.2 W typ. (8 TB), 6.7 W typ. (6 TB), 5.2 W typ. (4 TB)
Environmental
Temperature (operating / non-operating)	0 to 65° C / -40 to 70 °C, 5 to 60° C / -40 to 70 °C (12 TB - 16 TB)
Vibration (operating)	0.75 G (5 to 300 Hz) 0.25 G (300 to 500 Hz) or less
Vibration (non-operating)	3 G (5 to 500Hz) (10 TB - 16 TB), 5 G (5 to 500Hz) or less (4 TB - 8 TB)
Shock (operating)	70 G / 2 ms duration
Shock (non-operating)	250 G / 2 ms duration
Acoustics (idle mode)	20dB typ. (12 TB - 16 TB), 34 dB typ. (10 TB), 33 dB typ. (6 TB, 8 TB), 30 dB typ. (4 TB)
Acoustics (seek mode)	35 dB typ. (6 TB, 8 TB), 34 dB typ. (4 TB)

Physical
Dimensions	147 (L) x 101.85 (W) x 26.1 (H) mm
Weight (approx.)	770 g max. (6 TB - 10 TB), 720 g max. (4 TB, 12 TB - 16 TB)
Limited warranty	3 years

Product Range

Internal Hard Drive

S300

Always On, Always Watching

With surveillance systems, nothing but the best is good enough. The Toshiba 3.5-inch S300 is built to meet the highest demands. With support for up to 32 high-resolution surveillance video cameras simultaneously and up to 6 TB capacity, it brings everything into clear view. Each S300 is built with the highest-quality components and has passed rigorous tests to ensure 24/7 reliability and performance. That’s Toshiba quality you can trust under the harshest working conditions.

Use for:
• Network Video Recorders (NVR)
• Entry- and Mid-Range Surveillance NVR (SNVR) and SDVR Platforms
• Hybrid (analog and IP) SDVR Platforms

3.5″ SATA Hard Drive

Up to 5400 RPM

128 | 256 MB Buffer

24/7 Operation

Supports up to 64 Video Cameras

High Reliability and Enhanced Real-Time Performance

Toshiba Dynamic Cache Technology

Toshiba Stable Platter Technology

High-Endurance Design

3-year Warranty

6 TB 4 TB 2 TB

RELENTLESS RELIABILITY

Reliability is a function of component quality and testing. The S300 takes it to a new level, using optimised components to deliver the clear detail from up to 64 video cameras at the same time. Rigorous testing provides performance you can trust day in, day out.

ATTENTION TO DETAIL

When it comes to those events where even the single frame counts, the S300 has been designed to record even the smallest detail. 24/7 reliability and high-performance ensure you will capture every detail to analyze your security footage at any time.

S300 | Surveillance Hard Drives

TOSHIBA Surveillance HDDs deliver high reliability, comfortable operability, temperature durability and – of course – large capacity.

DESIGNED AND TESTED FOR COMPATIBILITY

The S300 has been designed and tested to support up to 64 high resolution cameras, allowing flexible scalability for your security camera systems. Compatible with DVR, NVR platforms, video servers and video management systems for around-the-clock security, the surveillance never sleeps – so that you can.

toshiba-internal-hard-drive-s300-surveillance

SMART PERFORMANCE DELIVERS

The S300 is a smart performer. That’s because Toshiba’s Dynamic Cache Technology optimises read and write cycle cach allocation through buffer management and a special on-board cache algorithm.

INTEGRATED RV SENSORS

Regular hard disk drives without RV sensors can affect the performance of a multi-bay system by generating ‘knock-on’ vibration. The S300 ensures high reliability by minimising vibration effects through their advanced control and sensing technology. Multiple sensors detect the slightest shock and built-in RV sensors also compensate for rotational vibration – eliminating the possibility of ‘knock-on’ vibration in multi-bay surveillance systems.

HIGH ENDURANCE, HIGH RELIABILITY

The high-endurance, high-performance components of the S300 withstand harsh environments for superior reliability. High-temperature environments trigger optimized seek speed to support lower power consumption while automatically reducing noise and vibration emissions. Up to one million hour MTTF (Mean time to failure) and 180 TB per year workload rating provide peace of mind when operating security camera systems.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system. A three year extended warranty is also included with the S300 for the ultimate peace of mind.

toshiba-internal-hard-drive-s300-warranty

Product Specifications

Product Range

S300 Hard Drives

Part number Capacity Buffer size Recording Type

HDWT860UZSVA 6 TB 256 MB SMR

HDWT840UZSVA 4 TB 256 MB SMR

HDWT720UZSVA 2 TB 128 MB SMR
MORE

HDWT140UZSVA 4 TB 128 MB CMR

HDWT740UZSVA 4 TB 128 MB SMR

HDWV110UZSVA 1 TB 128 MB SMR

Download Datasheet

Enterprise Hard Drive

AL Series – Performance

Enterprise-class performance

For business systems, failure just isn’t an option – so when you have mission-critical applications you need storage solutions that meet your needs. Toshiba’s Enterprise Performance Hard Drive – AL Series delivers high storage densities with rapid data transfer speed, backed up by a 5-year warranty. You can trust the AL Series to deliver day in and day out, 24/7, even in the most demanding high-performance server and storage systems. Especially when traffic is high, the hard drives have the speed needed to perform simultaneous transactions smoothly and efficiently. Additionally, proprietary technologies like the Toshiba Persistent Write Cache Technology and crypto options provide the assurance that your data will stay in safe hands.

Use for:
• Enterprise server and storage systems
• Business database server with high workloads
• Big data analytics
• Virtualized storage systems

2.5” SAS Hard Drive

Dual-port SAS Interface

24/7 Operation

Unlimited workload (TB/year)

MTTF of 2 mill. hours

Persistent Write Cache Technology

Flexible in Block Size and SIE and SED option

5-year warranty

PERFORMANCE ENTERPRISE STORAGE

With a range of capacities starting at 300 GB and reaching 2.4 TB and flexible, advanced technology options the AL Series offers the right solution for demanding high-performance and mission-critical enterprise applications.

PERFORMANCE FOR 24/7 OPERATION

Because data never sleeps, your storage solutions need to be ready at any time of the day or night, 24/7. We understand that your company needs to be ready to perform demanding business server operations, that’s why the AL Series delivers high performance at a workload of 550 TB/year and comes with a 128 MB cache. The series is specifically engineered for mission-critical IT operations, where low latency is of highest priority.

GETTING THE FULL DATA BANDWIDTH TO EVERY DRIVE

Every member of the AL Series features a high performance dual-port SAS interface that can reach and sustain 12 GB/s transfer rates, delivering excellent performance and additional safety in mission-critical systems. Enterprise users can work with confidence, knowing that their data paths will always be accessible and operating at fast speed with high reliability.

toshiba internal hard drive AL Enterprise class

ENTERPRISE-CLASS RELIABILITY

Enterprise users need flexibility – the AL Series meets this need with a choice of Advanced Format options and block size on demand (512e, 4Kn, 512n). Furthermore, every member of the AL Series comes with an industry-leading Mean Time To Failure (MTTF) of 2 million hours and a 5-year warranty, providing enterprise-class reliability for the ultimate peace of mind.

KEEPING YOUR CRITICAL DATA SAFE

Your data is critical so don’t risk losing it. Toshiba’s proprietary technologies have been developed to add security and assurance to the enterprise user. With Persistent Write Cache Technology your data is safe in the event of an interruption in power supply during a write to the hard disk. Data is saved in the large flash-based cache and written to the disk when power is restored.

toshiba internal hard drive AL Advanced_Technologies

toshiba internal hard drive AL Available_Option_Erase

TECHNOLOGY OPTIONS FOR PEACE OF MIND

Keeping your data secure is made simpler by choosing a Self Encrypting Drive (SED) from Toshiba. This feature option uses cryptography to encrypt data as it is written on the hard disk drive. Additonally, if you choose a hard drive with Sanitize Instant Erase (SIE) technology, all data can be erased in an instant without the need for overwriting the drive for hours.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system. A 5-year extended warranty is also included with the Enterprise Capacity Hard Drive – MG Series for the ultimate peace of mind.

Product Specifications

Product Range

Enterprise Hard Drive

MG Series – Capacity

Designed for your enterprise business

As Big Data drives demand for more distributed storage in the cloud and on premises, enterprise server and storage systems need to be built using trusted solutions. Toshiba’s Enterprise Capacity Hard Drive – MG Series offers formatted capacities as high as 20 TB with interface options including SATA and SAS and delivers 24/7 operation at a workload of 550 TB/year. The MG Series is ideal for enterprise storage array and industrial server and storage systems. It provides the capacity and advanced technologies to meet the special demands of datacenter and cloud-scale infrastructures.

Use for:
• Business critical enterprise server and storage systems with need for capacity
• Mainstream enterprise storage arrays (RAID, software defined)
• Cloud- and hyperscale storage systems
• Distributed file systems, Big Data
• Enterprise and cloud archive- and data recovery systems
• Centralized surveillance data storage systems
• Industrial server- and storage systems

3.5” SATA or SAS Hard Drive

24/7 operation

5-year warranty

Toshiba Stable Platter Technology

Persistent Write Cache technology

550 TB/year workload

Flexibility in block size and SIE and SED options

Rotational Vibrations sensor

HIGH CAPACITY ENTERPRISE STORAGE

With formatted storage capacities ranging from 1 TB to 20 TB the MG Series offers hard disk drive solutions for enterprise servers and storage systems with need for capacity.

DEMAND MORE, GET MORE

The enterprise demands more and with the MG Series you get it. Each member of the series has a workload rating of 550 TB/year, which is around ten times higher than an average desktop hard disk drive. This performance is available at any time of the day or night, as 24/7 operation also comes as standard.

INTEGRATED RV SENSORS

Regular hard disk drives can impact the performance of a multi-bay system by generating ‘knock-on’ vibration. The MG Series ensures high reliability by minimising vibration effects through their advanced control and sensing technology. Multiple sensors detect the slightest shock and built-in RV (Rotational Vibration) sensors compensate for any rotational vibration detected, eliminating the possibility of ‘knock-on’ vibration in multi-bay server systems.

toshiba internal hard drive MG RV_Sensor

toshiba-internal-hard-drive-AL-Advanced_Technologies-1

KEEPING YOUR CRITICAL DATA SAFE

Your data is critical so don’t risk it. Toshiba’s advanced technologies have been developed to add security and assurance to the enterprise user. With Persistent Write Cache Technology your data is safe in the event of an interruption in power supply during a write to the hard disk. Data is saved in the large flash-based cache and written to the disk when power is restored.

ADVANCED TECHNOLOGIES

Toshiba’s innovative Stable Platter Technology minimizes vibrations by stabilizing the motor shaft at both ends. And that means improved tracking accuracy and maximum performance during read and write operations. In addition, Toshiba’s Dynamic Cache Technology, a self-contained cache algorithm with on-board buffer management, optimizes how the cache is allocated during read/write to provide the high-level performance demanded by real-time domains.

toshiba internal hard drive MG Stable_Platter_Technology

HIGH STORAGE DENSITY LEVEL

The Conventional Magnetic Recording (CMR) HDDs with capacities of 12TB or higher use a helium-sealed design, providing the power-efficient capacity and storage density needed by cloud-scale and enterprise storage solution providers to achieve their TCO objectives. They also utilise Toshiba Group’s laser welding technology to ensure the helium remains securely sealed inside the drive enclosure. The MG10 Series features a 20 TB 10-disk model, while the MG09 Series features a 18 TB 9-disk model.

TOSHIBA’S UNIQUE TECHNOLOGY APPROACH

Writing data at the densities required for high-capacity HDDs calls for an advanced, innovative and reliable approach. Toshiba’s MG10 and MG09 series HDDs feature Flux Control Microwave Assisted Magnetic Recording (FC-MAMR) technology – a simple and elegant technique that uses microwave energy to ensure more of the write energy is focused into the platter, achieving an increase in areal density capability (ADC) of up to 20%. Toshiba’s technology uses conventional writing methods while eliminating the drawbacks of other MAMR approaches, allowing MG10 HDDs to achieve capacities up to 20 TB..

toshiba internal hard drive MG Available_Option_Erase

STORE MORE – WITH FLEXIBILITY

Enterprise users need flexibility – the MG Series meets this need with a choice of 6 Gbit/s SATA and dual-port 12 Gbit/s SAS interface options as well as block size on demand (512e, 4Kn, 512n). Additionally, there are options for Toshiba hard drives with Self Encrypting technology or with Sanitize Instant Erase (SIE) technology, which means that in an instant all data is erased, without the need for overwriting the drive for hours.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system. A 5-year extended warranty is also included with the Enterprise Capacity Hard Drive – MG Series for the ultimate peace of mind.

Product Specifications

Product Range

Part number	Capacity	Buffer Size
SATA \| MG10ACA****	20TB	512MB
SATA \| MG09ACA****	16TB / 18TB	512MB
SATA \| MG08ACA****	16TB	512MB
SATA \| MG07ACA****	12TB / 14TB	256MB
SATA \| MG06ACA****	10TB / 8TB / 6TB	256MB
SATA \| MG08ADA****	4TB / 6TB / 8TB	256MB
SATA \| MG04ACA****	2TB / 1TB	128MB
SAS \| MG09SCA****	16TB / 18TB	512MB
SAS \| MG08SCA****	16TB	512MB
SAS \| MG07SCA****	14TB / 12TB	256MB
SAS \| MG06SCA****	10TB / 8TB / 6TB	256MB
SAS \| MG08SDA****	4TB / 6TB / 8TB	256MB
SAS \| MG04SCA****	2TB / 1TB	128MB

Internal Hard Drive

V300

Stream. Record. Edit.

Toshiba’s 3.5-inch V300 Video Streaming Hard Drive with up to 3 TB lets you stream, record, edit and play video content on DVR, TV or NVR – with all the efficiency and reliability you need. A 64 MB buffer helps deliver smooth performance, while temperature control technology limits heat buildup, extending service life for added reliability. A drive that’s quiet and more efficient than ever, thanks to Toshiba’s Silent Seek Technology, and reduced energy consumption.

Use for:
• Video Editing Systems
• Set-Top-Box (STB)
• Digital Video Recorders (DVR)
• Network Video Recorders (NVR)
• Video Surveillance Systems

3.5″ SATA Hard Drive

64 MB buffer

24/7 operation

Toshiba Silent Seek Technology

Temperature control

3 TB 2 TB 1 TB 500 GB

CAPACITY AT YOUR SERVICE

The V300 is available in a range of storage capacities to meet your specific requirements, with up to 3 TB. This series of 3.5-inch internal HDDs all come with a 64 MB internal data buffer, to ensure your video experience never slows down. And with an industry-standard SATA interface providing up to 6 GBit/s transfer, the action never stops!

STREAMING PERFORMANCE YOU CAN DEPEND ON

Designed for the reliable delivery of multiple and simultaneous high resolution streams, the V300 takes video content delivery to another level. A 64 MB buffer helps to deliver smooth performance while longer service-life reliability through curbed heat generation helps prevent overheating.

V300 | Video Streaming Hard Drives

TOSHIBA Video Streaming HDDs to record, collect, edit and stream the video content you are interested in. With the temperature control technology, it extends service life for added reliability.

OPTIMISED FOR THE VIEWER’S EXPERIENCE

The speed and performance of the V300 is delivered with a whisper, thanks to Toshiba’s Silent Seek Technology to minimize noise and heat during operation. The low acoustics of the hard drive are optimized for the simlutaneous recording and streaming offered by today’s DVRs and STBs. With quality like this, nothing gets in the way of a great viewing and listening experience.

toshiba-internal-hard-drives-v300-silent-seek-technology

toshiba-internal-hard-drive-v300-heat-prevention

KEEPING COOL WHEN THE ACTION HEATS UP

The efficient low spin design of the V300 helps to lower the energy consumption for video recording, editing and streaming features by up to 25% (compared to the P300, 7200 rpm model). With an extended temperature range, the hard drive is optimized for today’s standard video recorders and set-top boxes, even when placed in high-temperature environments.

BUILT TO DELIVER, DESIGNED TO LAST

toshiba-internal-hard-drive-v300-warranty

Product Specifications

Basic Specifications


Power Management
Supply voltage	5V DC ±5%; 12V DC ±10%
Consumption (operating)	5.40 W typ. (3 TB), 4.70 W typ. (2 TB), 5.70 W typ. (500 GB, 1 TB)
Consumption - Active Idle	4.20 W typ. (3 TB), 3.30 W typ. (2 TB), 3.00 W typ. (500 GB, 1 TB)

Environmental
Operating temperature	0.67 G (5 to 500 Hz)
Temperature (operating / non-operating)	0 - 65° C / -40 - 70° C
Vibration (operating)	0.67 G (5 to 500 Hz)
Vibration (non-operating)	1.04 G (2 to 200Hz)
Shock (operating)	70 G / 2 ms duration
Shock (non-operating)	300 G / 2 ms half sine
Acoustics (idle mode)	24 dB typ. (3 TB), 22 dB typ. (2 TB), 19 dB typ. (500 GB - 1 TB)
Limited Warranty	3 years

Product Range

Internal Hard Drive

L200

Take your laptop to the next level

Toshiba’s 2.5-inch L200 Laptop PC Hard Drive is designed for everyday laptop users and gamers – and it’s ideal for boosting and upgrading the storage capacity of your laptop PC or games console by up to 2 TB – with up to 128 MB buffer. Toshiba’s Dynamic Cache Technology can further enhance access performance. Available in capacities of up to 2 TB, the L200 puts the renowned durability and reliability of Toshiba technology to work in your notebook or game console.

Use for:
• Notebooks
• Game consoles
• External enclosures

2.5″ SATA Hard Drive

5400 rpm

128 MB / 8 MB buffer

Toshiba Dynamic Cache Technology

Advanced Format

2 TB1 1 TB1 500 GB

UPGRADE YOUR SPACE

For a large upgrade in a small device, the L200 HDD is capable of adding up to 2 TB to laptops or game consoles, for quick and easy access to large gaming files, or everyday documents and media. It comes with up to 128 MB buffer.

1Drive-Managed SMR (Shingled Magnetic Recording) Technology

KEEP DATA SECURE

The L200’s design includes an internal shock sensor, ensuring none of your data is lost. In addition, ramp loading technology means that when the hard drive, game console or notebook are being transported, the drive slider does not make contact with the disk, making your data more secure.

OPTIMIZED CACHE ALLOCATION

Toshiba’s Dynamic Cache Technology, a self-contained cache algorithm with on-board buffer management, optimizes how the cache is allocated during read/write to provide the high-level performance demanded by real-time applications.

toshiba-internal-hard-drive-l200-optimized-cache-1

toshiba-internal-hard-drives-l200-access_performance-1

ENHANCED ACCESS PERFORMANCE

The read and write access sequence performance is further enhanced through innovative techniques to minimize head movement and disk revolutions. Optimized data access sequence helps improve performance and minimize mechanical workload from the drive.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system.

toshiba-internal-hard-drive-l200-warranty

Product Specifications

toshiba-internal-hard-drives-dimension-l200

Product Range

L200 Laptop Drives

Part number Capacity Buffer size Recording Type

HDWL120UZSVA (Bulk) 2 TB 128 MB SMR

HDWL110UZSVA (Bulk) 1 TB 128 MB SMR

HDWK105UZSVA (Bulk) 500 GB 8 MB CMR

Download Datasheet

Internal Hard Drive

P300

Performance meets reliability

Toshiba’s 3.5-inch P300 Desktop PC Hard Drive delivers a high performance for professionals. With its dual-stage actuator, you can count on smooth, responsive computing. What’s more, your data and media is secured with a ramp loading design, as well as a shock sensor. The P300 is available in capacities up to 6 TB.

Use for:
• Powerful Desktop Workstations
• All-in-one PCs
• Desktop PCs
• External Enclosures
• Gaming Computers

3.5″ SATA Hard Drive

7200 / 5400 rpm

128 / 256 MB buffer

Advanced Format

6 TB 4 TB 2 TB

POWERFUL STORAGE

The P300 is ideal for graphic designers and creative professionals looking for a powerful performance. Available in storage capacities of up to 6 TB, with fast read and write speeds and a secure design.

PERFORMANCE ALONGSIDE RELIABILITY

The P300’s dual-stage actuator, available in the 2TB to 6TB models, improves positional accuracy, negating the effects on head-track alignment that vibrations can cause. This design makes for more precise, faster read and write speeds, and instant access to your data.

ENHANCED ACCESS PERFORMANCE

The data read/write access sequence performance is further enhanced through innovative techniques to minimize head movement and disk revolutions. Optimized data access sequence helps improve performance and minimize mechanical workload from the drive.

toshiba-internal-hard-drives-p300-advanced-read-and-write_revised

KEEP DATA SECURE

The P300’s design includes an internal shock sensor, ensuring no data is lost. In addition, ramp loading technology means that when your hard drive or desktop PC are being transported, the drive slider does not make contact with the disk and risk wearing or data loss.

BUILT TO DELIVER, DESIGNED TO LAST

toshiba-internal-hard-drive-p300-warranty

Product Specifications

toshiba-internal-hard-drives-dimension-p300

Product Range

P300 Desktop Drives

Part number Capacity Buffer size Recording Type

HDWD260UZSVA (Bulk) 6 TB 128 MB SMR

HDWD260AZSTA (Retail) 6 TB 128 MB SMR

HDWD240UZSVA (Bulk) 4 TB 128 MB SMR

HDWD240AZSTA (Retail) 4 TB 128 MB SMR

HDWD320UZSVA (Bulk) 2 TB 256 MB SMR

HDWD320AZSTA (Retail) 2 TB 256 MB SMR

Download Datasheet

Internal Hard Drive

S300

Capture every detail

Toshiba’s 3.5-inch S300 Surveillance Hard Drive is designed and tested for 24/7 reliable surveillance, built for speed, capacity, and longer content retention. Capture and analyse every frame from up to 64 video cameras in high resolution with the S300. Space is important to continually capture a history of video evidence over a period of time. With up to 10 TB you get the capacity to record and play back the events in real-time in high resolution and with object identification and face recognition.

Use for:
• Surveillance Digital Video Recorders (sDVR)
• Surveillance Network Video Recorders (sNVR)
• Hybrid sDVR (analog and IP)
• RAID Storage Arrays for Surveillance

3.5″ SATA Hard Drive
Up to 7200 rpm
256 / 128 MB buffer
24/7 operation
Supports up to 64 video cameras
High reliability and enhanced real-time performance
Toshiba Dynamic Cache Technology
Toshiba Stable Platter Technology
High-endurance design
3-year warranty

10 TB 8 TB 6 TB 4 TB

BUILT TO PERFORM

With up to 10 TB of storage capacity and support for up to 64 video cameras, the S300 ensures mission-critical surveillance continually records. Real-time drive performance allows higher-resolution video recording and streaming and longer content retention.

CAPTURE EVERY FRAME, ANALYSE EVERY DETAIL

When analyzing security footage, you can’t risk any frame drops. That’s why your storage has to provide ultimate performance to detect rapid movements, record the smallest details, and perform face recognition. The S300 has been designed to meet your specialist demands and is built for 24/7 reliability and high-performance to help you never miss a thing.

S300 | Surveillance Hard Drives

TOSHIBA Surveillance HDDs deliver high reliability, comfortable operability, temperature durability and – of course – large capacity.

DESIGNED AND TESTED FOR COMPATIBILITY

The S300 has been designed and tested to support up to 64 high resolution cameras, allowing flexible scalability for your security camera systems. Compatible with DVR, NVR, video servers and video management systems for around-the-clock security, the surveillance never sleeps – so that you can.

INDUSTRY-LEADING PERFORMANCE

A 256 MB buffer and high transfer rates meet the demands of surveillance data from higher-resolution camera streams. Improved real-time drive performance is achieved through Toshiba’s Dynamic Cache Technology optimizing read and write cycle cache allocation through an on-board cache algorithm and buffer management.

INTEGRATED RV SENSORS

HIGH ENDURANCE, HIGH RELIABILITY

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system. A three year extended warranty is also included with the S300 for the ultimate peace of mind.

Product Specifications

Basic Specifications
Form factor	3.5-inch
Interface	SATA 6.0 Gbit/s
Number of cameras supported	64 (6 TB -10 TB), 32 (4 TB)
Drive bays supported	8+ (6 TB -10 TB), 1-8 (4 TB)
Rotational Vibration (RV) Sensors	Yes
Advanced Format (AF)	Yes
RoHS compatible	Yes
Halogen Free	Yes
Shock Sensor	Yes

Performance
Rotational speed	7200 rpm (6 TB - 10 TB), 5400 rpm (4 TB)
Max. data transfer speed (sustained)	248 MB/s Typ. (10 TB), 241 MB/s Typ. (6 TB, 8 TB), 157 MB/s Typ. (4 TB)
Buffer size	256 MB (6 TB - 10 TB), 128 MB (4 TB)
Average latency	4,17 ms (6 TB - 10 TB), 5,56 ms (4 TB)
Native Command Queing (NCQ)	supported

Reliability
Workloads	180 TB/year (6 TB - 10 TB), 110 TB/year (4 TB)
MTTF	1.000.000 hours
Unrecoverable error rate	1 per 10E14 bits read
24/7 operation	Yes
Load / Unload Cycle	600.000

Power Management
Supply voltage	5V DC +6/-5%; 12V DC ±10% (6TB - 10TB); 5V DC ±5%; 12V DC ±10% (4TB)
Consumption (operating)	9.48 W typ. (10 TB), 8.61 W typ. (8 TB), 7.88 W typ. (6 TB), 7.5 W typ. (4 TB)
Consumption - Active Idle	7.15 W typ. (10 TB), 6.33 W typ. (8 TB), 5,59 W typ. (6 TB), 4.00 W typ. (4 TB)
Environmental
Temperature (operating / non-operating)	0 - 70° C / -40 - 70° C
Vibration (operating)	0.75 G (5 to 300 Hz) 0.25 G (300 to 500 Hz)
Vibration (non-operating)	3.0 G (5 to 500Hz) (6 TB - 10 TB); 5 G (5 to 500Hz) or less (4 TB)
Shock (operating)	70 G / 2 ms duration
Shock (non-operating)	250 G / 2 ms duration (6 TB - 10 TB), 300 G / 2 ms duration (4 TB)
Acoustics (idle mode)	34 dB typ. (6 TB - 10 TB), 26 dB typ. (4 TB)

Physical
Dimensions	147 (L) x 101.85 (W) x 26.1 (H) mm
Weight (approx.)	770 g max. (6 TB - 10 TB), 720 g max. (4 TB)
Limited warranty	3 years

Product Range

Internal Hard Drive

X300

Level up your drive performance

Toshiba’s 3.5-inch X300 Performance Hard Drive is designed for your professional or gaming PC – delivering reliable, large capacity, incredibly high-performance storage, made possible by a number of advanced features, including an ultra-high 512 MB, 256 MB or 128 MB buffer. It even features improved positional accuracy for stable recording. The X300 is available in capacities of up to 16 TB – ideal for PC gamers, graphic designers, and other users with demanding storage requirements.

Use for:
• Powerful desktop workstations
• All-in-one PCs
• Gaming computers
• High performance PCs
• Home media computers

3.5″ SATA Hard Drive

7200 rpm

512 MB / 256 MB / 128 MB buffer

Toshiba Dynamic Cache Technology

Toshiba Stable Platter Technology

16 TB 14 TB 12 TB 10 TB 8 TB 6 TB 4 TB

POWERFUL PERFORMANCE

Performing at 7200 RPM, and with a 512 MB, 256 MB or 128 MB buffer, your data is stored securely and accessed quickly. Whether it’s a quick game save, a large file that needs backing up, or working with multiple applications, the X300 retains its high-performance all day, every day. Ideal for graphic designers and creative professionals, the X300 is capable of handling almost any workload.

GAME ON. AND ON. AND ON.

When you need more, the X300 delivers. Available in storage capacities of up to 16 TB, the X300 is able to meet your every requirements, with fast read and write speeds and secure design, making it ideal for demanding roles such as professional computing and PC gaming.

RESPONDS IN AN INSTANT

The X300’s dual-stage actuator design improves positional accuracy, negating the effects on head-track alignment that vibrations can cause. This design makes for more precise, faster read and write speeds for instant access to your data.

toshiba-internal-hard-drives-x300-responds

ACCURATE TRACKING

Vibration is one big enemy of reliable HDD operation. Toshiba’s Innovative Stable Platter Technology minimizes vibrations by stabilizing the motor shaft at both ends. And that means improved tracking accuracy and maximum performance during read and write operations.

KEEP DATA SECURE

The X300’s design includes an internal shock sensor, ensuring no data is lost. In addition, ramp loading technology means that when the hard drive or desktop PC are being transported, the drive slider does not make contact with the disk, minimising the risk of wear or data loss.

toshiba-internal-hard-drives-e300-data-secure

toshiba-internal-hard-drive-x300-warranty

BUILT TO DELIVER, DESIGNED TO LAST

Product Specifications


Power Management
Supply voltage	5VDC (±5%) / 12VDC (±5%)
Consumption (operating)	6.91 W typ. (16 TB), 6.77 W typ. (12 TB - 14 TB), 9.92 W typ. (10 TB), 9.2 W typ. (8 TB), 11.3 W typ. (4 TB - 6 TB)
Consumption - Active Idle	4.03 W typ. (16 TB), 4.54 W typ. (12 TB - 14 TB), 7.22 W typ. (10 TB), 6.2 W typ. (8 TB), 7.5 W typ. (4 TB - 6 TB)

Environmental
Temperature (operating / non-operating)	5 to 60° C / -40 to 70 °C
Vibration (operating)	0.75 G (5 to 300 Hz), 0.25 G (300 to 500 Hz)
Vibration (non-operating)	3.0 G (5 to 500Hz) (10 TB - 16 TB), 5 G (5 to 500Hz) or less (4 TB - 8 TB)
Shock (operating)	70 G / 2 ms duration
Shock (non-operating)	250 G / 2 ms duration (8 TB - 16 TB), 300 G / 2 ms duration (4 TB - 6 TB)
Acoustics (idle mode)	20 dB typ. (12 TB - 16 TB), 34 dB typ. (10 TB, 6 TB), 33 dB typ. (8 TB), 31 dB typ. (4 TB)

Physical
Dimensions	147 (L) x 101.6 (W) x 26.1 (H) mm
Weight (approx.)	770 g max. (6 TB-10 TB), 720 g max. (4 TB, 12 TB - 16 TB)
Limited warranty	2 years

Product Range

Product Overview (Click on PDF to download)

Internal HDD Firmware Update

Part number	Capacity	Buffer Size
AL14SXB*E	900GB / 600GB / 300GB	128MB
AL15SEB*E	2.4TB / 1.8TB / 1.2TB / 900GB / 600GB / 300GB	128MB
AL14SEB*E	1.8TB / 1.2TB / 900GB / 600GB	128MB
AL14SEB***N	1.2TB / 900GB / 600GB / 450GB / 300GB	128MB

Part number	Capacity	Buffer Size
HDWU130UZSVA	3TB	64MB
HDWU120UZSVA	2TB	64MB
HDWU110UZSVA	1TB	64MB
HDWU105UZS5A	500GB	64MB
