Internal Hard Drive

P300

Performance meets reliability





Icon_PC

Toshiba’s 3.5-inch P300 Desktop PC Hard Drive delivers a high performance for professionals. With its dual-stage actuator, you can count on smooth, responsive computing. What’s more, your data and media is secured with a ramp loading design, as well as a shock sensor. The P300 is available in capacities up to 6 TB.

Use for:
• Powerful Desktop Workstations
• All-in-one PCs
• Desktop PCs
• External Enclosures
• Gaming Computers





P300_Gallery_Images_03

     3.5″ SATA Hard Drive

    7200 / 5400 rpm

    64 / 128 / 256 MB buffer

    Advanced Format

  • P300_Gallery_Images_01
  • P300_Gallery_Images_02

6 TB     4 TB     3 TB     2 TB     1 TB     500 GB

POWERFUL STORAGE

The P300 is ideal for graphic designers and creative professionals looking for a powerful performance. Available in storage capacities of up to 6 TB, with fast read and write speeds and a secure design.

PERFORMANCE ALONGSIDE RELIABILITY

The P300’s dual-stage actuator, available in the 2TB to 6TB models, improves positional accuracy, negating the effects on head-track alignment that vibrations can cause. This design makes for more precise, faster read and write speeds, and instant access to your data.

ENHANCED ACCESS PERFORMANCE

The data read/write access sequence performance is further enhanced through innovative techniques to minimize head movement and disk revolutions. Optimized data access sequence helps improve performance and minimize mechanical workload from the drive.





toshiba-internal-hard-drives-p300-advanced-read-and-write_revised





toshiba-internal-hard-drives-p300-keep-data-secure

KEEP DATA SECURE

The P300’s design includes an internal shock sensor, ensuring no data is lost. In addition, ramp loading technology means that when your hard drive or desktop PC are being transported, the drive slider does not make contact with the disk and risk wearing or data loss.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system.





toshiba-internal-hard-drive-p300-warranty



Product Specifications

toshiba-internal-hard-drives-dimension-p300
Basic Specifications
Form Factor 3.5-inch
Interface SATA 6.0 Gbit/s
Advanced Format (AF) Yes
RoHS Compatible Yes
Halogen Free Yes
Shock Sensor Yes
Performance
Recording Technology CMR (Conventional Magnetic Recording) / SMR (Shingled Magnetic Recording)
Rotational Speed 7200 RPM (500 GB - 3 TB), 5400 RPM (2 TB - 6 TB)
Buffer size 64 MB (500 GB - 3 TB) 128 MB (2 - 6 TB) 256 MB (2 TB)
Average latency 4.17 ms
Native Command Queing (NCQ) supported
Reliability
Unrecoverable error rate 1 per 10E14 bits read
Load / Unload Cycle 300.000 (500 GB - 3 TB), 600.000 (2 TB - 6 TB)
Power Management
Supply voltage 5VDC (±5%) / 12VDC (±10%)
Consumption – Read/Write 6.40 W typ. (500 GB, 1 TB, 3 TB), 5.80 W typ. (2 TB) 4.46 W typ. (6 TB) 4.11 W typ. (4 TB) 4.14W typ. / 5.21W typ. (2 TB)
Consumption – Low Power Idle 5.20 W typ. (3 TB), 4.40 W typ. (2 TB), 3.70 W typ. (500 GB, 1 TB) 2.68 W typ. (6 TB) 2.32 W typ. (4 TB) 2.11W typ. / 2.92W typ. (2TB)
Environmental
Temperature (operating / non-operating) 0 to 65° C / -40 to 70 °C (500 GB - 3 TB), 0 to 60° C / -40 to 65 °C (2 TB, 6 TB), 0 to 60° C / -40 to 70 °C (2 TB)
Vibration (operating) 0.67 G (5 to 500 Hz) (500 GB - 3 TB) 0.50 G (5 to 350 Hz) (2 TB - 6 TB)
Vibration (non-operating) 1.04 G (2 to 200 Hz) (500 GB - 3 TB), 3.0 G (5 to 500 Hz) (2 TB - 6 TB)
Shock (operating) 70 G / 2 ms duration
Shock (non-operating) 300 G (2 ms half sine) (2 TB, 3 TB, 6 TB) 350 G (2 ms half sine) (500 GB, 1 TB, 2 TB, 4 TB)
Acoustics (idle mode) 27 dB typ. (3 TB, 2 TB), 25 dB typ. (1 TB, 500 GB) 24 dB typ. (6 TB) 22 dB typ. (4 TB) 21dB typ. / 25dB typ. (2 TB)
Acoustics (seek mode) 28 dB typ. (3 TB, 2 TB), 26 dB typ. (1 TB, 500 GB) 25 dB typ. (6 TB) 24 dB typ. (4 TB) 26 dB typ. (2 TB)
Physical
Dimensions 147 (L) x 101.6 (W) x 26.1 (H) mm
Weight (approx.) 680 g max. (2 TB, 3 TB) 450 g max. (500 GB, 1 TB) 680 g max (6 TB) 650 g max. (4TB) 440 g max. (2 TB)
Limited warranty 2 years

Product Range

Series Part number Capacity Buffer Size Rotation Speed Recording Type
DT02 HDWD260UZSVA 6TB 128MB 5400RPM SMR
DT02 HDWD240UZSVA 4TB 128MB 5400RPM SMR
DT02 HDWD220UZSVA 2TB 128MB 5400RPM SMR
DT02 HDWD320UZSVA 2TB 256MB 7200RPM SMR
DT01 HDWD130UZSVA 3TB 64MB 7200RPM CMR
DT01 HDWD120UZSVA 2TB 64MB 7200RPM CMR
DT01 HDWD110UZSVA 1TB 64MB 7200RPM CMR
         Product Overview (Click to download)    Product Overview (Click on PDF to download)
