04_PRODUCT_PAGE_Header_S300



Internal Hard Drive

S300

Capture every detail





Icon_Surveillance



Toshiba’s 3.5-inch S300 Surveillance Hard Drive is designed and tested for 24/7 reliable surveillance, built for speed, capacity, and longer content retention. Capture and analyse every frame from up to 64 video cameras in high resolution with the S300. Space is important to continually capture a history of video evidence over a period of time. With up to 10 TB you get the capacity to record and play back the events in real-time in high resolution and with object identification and face recognition.

Use for:
• Surveillance Digital Video Recorders (sDVR)
• Surveillance Network Video Recorders (sNVR)
• Hybrid sDVR (analog and IP)
• RAID Storage Arrays for Surveillance





S300_Gallery_Images_03
  • 3.5″ SATA Hard Drive
  • Up to 7200 rpm
  • 256 / 128 MB buffer
  • 24/7 operation
  • Supports up to 64 video cameras
  • High reliability and enhanced real-time performance
  • Toshiba Dynamic Cache Technology
  • Toshiba Stable Platter Technology
  • High-endurance design
  • 3-year warranty

  • S300_Gallery_Images_01
  • S300_Gallery_Images_02

10 TB     8 TB     6 TB     4 TB

BUILT TO PERFORM

With up to 10 TB of storage capacity and support for up to 64 video cameras, the S300 ensures mission-critical surveillance continually records. Real-time drive performance allows higher-resolution video recording and streaming and longer content retention.

CAPTURE EVERY FRAME, ANALYSE EVERY DETAIL

When analyzing security footage, you can’t risk any frame drops. That’s why your storage has to provide ultimate performance to detect rapid movements, record the smallest details, and perform face recognition. The S300 has been designed to meet your specialist demands and is built for 24/7 reliability and high-performance to help you never miss a thing.







S300 | Surveillance Hard Drives

TOSHIBA Surveillance HDDs deliver high reliability, comfortable operability, temperature durability and – of course – large capacity.

DESIGNED AND TESTED FOR COMPATIBILITY

The S300 has been designed and tested to support up to 64 high resolution cameras, allowing flexible scalability for your security camera systems. Compatible with DVR, NVR, video servers and video management systems for around-the-clock security, the surveillance never sleeps – so that you can.





toshiba-internal-hard-drive-s300-surveillance





toshiba-internal-hard-drive-s300-performance

INDUSTRY-LEADING PERFORMANCE

A 256 MB buffer and high transfer rates meet the demands of surveillance data from higher-resolution camera streams. Improved real-time drive performance is achieved through Toshiba’s Dynamic Cache Technology optimizing read and write cycle cache allocation through an on-board cache algorithm and buffer management.

INTEGRATED RV SENSORS

Regular hard disk drives without RV sensors can affect the performance of a multi-bay system by generating ‘knock-on’ vibration. The S300 ensures high reliability by minimising vibration effects through their advanced control and sensing technology. Multiple sensors detect the slightest shock and built-in RV sensors also compensate for rotational vibration – eliminating the possibility of ‘knock-on’ vibration in multi-bay surveillance systems.





toshiba-internal-hard-drive-s300-RV_Sensor





toshiba-internal-hard-drive-s300-endurance_reliability

HIGH ENDURANCE, HIGH RELIABILITY

The high-endurance, high-performance components of the S300 withstand harsh environments for superior reliability. High-temperature environments trigger optimized seek speed to support lower power consumption while automatically reducing noise and vibration emissions. Up to one million hour MTTF (Mean time to failure) and 180 TB per year workload rating provide peace of mind when operating security camera systems.

BUILT TO DELIVER, DESIGNED TO LAST

Toshiba is renowned the world over for 50 years of leading innovation – and the power behind its range of hard drives is no exception. Designed for high capacity and excellent performance, you can be sure that Toshiba’s wealth of experience in hard drives is at work in your storage system. A three year extended warranty is also included with the S300 for the ultimate peace of mind.





toshiba-internal-hard-drive-s300-warranty



Product Specifications

toshiba-internal-hard-drives-dimension-x300
Basic Specifications
Form factor 3.5-inch
Interface SATA 6.0 Gbit/s
Number of cameras supported 64 (6 TB -10 TB), 32 (4 TB)
Drive bays supported 8+ (6 TB -10 TB), 1-8 (4 TB)
Rotational Vibration (RV) Sensors Yes
Advanced Format (AF) Yes
RoHS compatible Yes
Halogen Free Yes
Shock Sensor Yes
Performance
Rotational speed 7200 rpm (6 TB - 10 TB), 5400 rpm (4 TB)
Max. data transfer speed (sustained) 248 MB/s Typ. (10 TB), 241 MB/s Typ. (6 TB, 8 TB), 157 MB/s Typ. (4 TB)
Buffer size 256 MB (6 TB - 10 TB), 128 MB (4 TB)
Average latency 4,17 ms (6 TB - 10 TB), 5,56 ms (4 TB)
Native Command Queing (NCQ) supported
Reliability
Workloads 180 TB/year (6 TB - 10 TB), 110 TB/year (4 TB)
MTTF 1.000.000 hours
Unrecoverable error rate 1 per 10E14 bits read
24/7 operation Yes
Load / Unload Cycle 600.000
Power Management
Supply voltage 5V DC +6/-5%; 12V DC ±10% (6TB - 10TB); 5V DC ±5%; 12V DC ±10% (4TB)
Consumption (operating) 9.48 W typ. (10 TB), 8.61 W typ. (8 TB), 7.88 W typ. (6 TB), 7.5 W typ. (4 TB)
Consumption - Active Idle 7.15 W typ. (10 TB), 6.33 W typ. (8 TB), 5,59 W typ. (6 TB), 4.00 W typ. (4 TB)
Environmental
Temperature (operating / non-operating) 0 - 70° C / -40 - 70° C
Vibration (operating) 0.75 G (5 to 300 Hz) 0.25 G (300 to 500 Hz)
Vibration (non-operating) 3.0 G (5 to 500Hz) (6 TB - 10 TB); 5 G (5 to 500Hz) or less (4 TB)
Shock (operating) 70 G / 2 ms duration
Shock (non-operating) 250 G / 2 ms duration (6 TB - 10 TB), 300 G / 2 ms duration (4 TB)
Acoustics (idle mode) 34 dB typ. (6 TB - 10 TB), 26 dB typ. (4 TB)
Physical
Dimensions 147 (L) x 101.85 (W) x 26.1 (H) mm
Weight (approx.) 770 g max. (6 TB - 10 TB), 720 g max. (4 TB)
Limited warranty 3 years

Product Range

Part number Capacity Buffer Size
HDWT31AUZSVA 10TB 256MB
HDWT380UZSVA 8TB 256MB
HDWT360UZSVA 6TB 256MB
HDWT140UZSVA 4TB 128MB
